UV Dryer Machine/IR Heating Leveling Machinee/Heater Drying Machine
Application:
1. The heating leveller adopts advanced infrared heating technology abroad, which can heat the paint film on the surface of the workpiece after painting in a very short time, so that the paint on the surface of the workpiece can be leveled and dried rapidly.
2. Equipped with axial-flow fan to enhance the internal air flow, make the temperature more uniform, eliminate the air bubbles and unequal defects formed on the surface of the workpiece in the painting process, improve the surface quality of the painting, make the workpiece surface smooth and full.
3. This machine is suitable for flat surface or certain concave-convex surface workpiece. It can be used alone or in conjunction with automatic jet and UV surface painting machine.
UV Dryer Machine/Flash-off Machine/Heater dryer Machine
Technical Data
(All Machine Both can be customize it as client require)
Model | ICHG600 | ICHG1000 | ICHG1300 |
Working Width | 600mm | 1000mm | 1300mm |
Working Thickness | 0-100mm | 0-100mm | 0-100mm |
Feeding Speed | 2-20m/mim | 2-20m/mim | 2-20m/mim |
Feeding Power | 1.5kw | 1.5kw | 1.5kw |
Fan Power | 0.24kw | 0.64kw | 0.64kw |
Total Power | 10.74kw | 11.94kw | 29.14kw |
Dimension(L*W*H) | 6120*1060*1400mm | 6120*1460*1400mm | 6120*1760*1400mm |
Net Weight | 1890kg | 2260kg | 2300kg |
Packege
All Machine Both can be customzied, welcome inquiry directly. 24Hours Service.
